House Service Fuse Holder – 500V 5A to 100A Fused 125A Solid Link

Specification Description:
Cooper Bussmann House Service fuse base is suitable to use with BS fuse links which are 22mm or 30mm Diameter x 57mm long

Dimensions:
See illustraction

Ratings:
Voltage – 500 Vac
Current – 100A fused – 125A Solid link

Agency information:
EN 60269, AS 60269

Features and Benefits:
• Thermoplastic housing, ensures long mechanical life
• Supply Authority sealable, increased security
• Single hole fixing
• Bright tinned contacts with fuse size stamping, for extended life and easy identification
• Captive terminal screws ensures quick cable connections
• Large cable entries up to 35mm
• Front or Back wire options

House Service Fuseholder

Amp

Fuse

Description

IPD

Bussmann

100

22 x 57mm

‘KR85’

Front wired

S71002ABWS

HSB22BW-VI

Back wired

S71002AFWS

HSB22FW

30 x 57mm

‘LR85’

Front wired

S71002BBWAI

HSB30BWI

Back wired

S71002BFWAI

HSB30FWI

Front wired

S7CLRBBWAI

HSB30BWCLI

Back wired

S7CLR2BFWAI

HSB30FWCLI

125

Qld Only

Front wired

S7125BWQ

HSB22BWCL-Q

Back wired

S7125FWQ

HSB22FWCL-Q

The information in this data sheets gives general characteristics of the material. Whilst all possible care has been taken to ensure this information is correct the manufacturer cannot accept any liability nor is any liability on the part of the manufacturer or supplier to be implied as a result of the data given as conditions and methods of use are beyond our control. The user must confirm suitability for the application prior to commercial use.
